Downward brace

3 - Box Frame Type and Details

A) Kerb principal truss

a) Kerb principal b) Crown strut c) Queen strut d) Interrupted collar e) Princess strut g) Downward & ogee brace

4 - Braces (I)

a) Downward brace b) lntegral bracket c) Upward brace d) Windbrace e) Corner brace f) Concealed brace g) Bracket h) Sill beam

5 - Braces

a) Stud brace b) Downward brace c) Soulace d) Wall plate e*) Ashlar piece

23 - Wall Frames

B) Large square panels C) Three-panel high framing D) Small square panels E) Close studding (storey high) F) Close studding (with mid-rail) G) Close studding square panels

d*) Stud f*) Rail n*) Mid rail p) Downward brace q*) Girding beam
