Applied Jetty

Jetty with a short side beam (the jetty spur), tenoned into a post behind the jetty

Back to all words

15 - Jetties (II)

15 - Jetties (II)

A*) Applied jetty B*) End jetty

a) Flying wall plate b) Jetty bressumer (two construction forms) c*) Storey post d) Jetty bracket j*) Jetty spur



15 - Jetties

15 - Jetties

A*) Applied jetty B*) End jetty C) Storeyed construction

c*) Storey post e) Passing braces f) clasped wall plate held by g) Doubled tiebeam h) Short knee principal i) Head plate j*) Jetty spur
